Jianghai Super Capacitor

From the Capacitor Supplier and Energy Storage Solution Provider

jianghai super capacitor
What are Energy Capacitors?

In times of e-mobility and generally when storing energy, often the energy storage devices are the limiting components in an application. Good ideas are rejected and potential is given away if the required energy can not be provided. This is exactly where energy capacitors are used. The concept is divided into two key technologies with completely individual characteristics.

EDLC

The basic technology is the classic Electric Double Layer capacitor (also known as Supercap or Ultracap). This technology is based on the storage of charge in the characteristic double layer. Two symmetrically arranged activated carbon electrodes are used, which are optimally suited to form a double layer.

LI-C

Lithium capacitors are a further development of the EDLCs. Here, the cathode electrode is replaced by a lithium ion doped graphite electrode, similar to a lithium ion battery. The asymmetric design optimizes the capacitance formation of the electrodes. This allows much higher capacitance value than previously possible with EDLC technology. This closes the gap between capacitor and battery.

Jianghai Standard Product Line-Up*

Electric Double Layer Capacitor (EDLC)

  • Coin Type Cells
    • SCV Series (standard): 5.SV, 0.1-1.SF
    • SVQ Series (high-temp): 5.SV, 0.1-1.SF
    • SVT Series (wide-temp): 5.SV, 0.1-lF
  • Radial Lead
    • SRP Series (standard): 2.7V, 1-100F
    • SRQ Series (high-temp): 2.7V, 1-S0F
    • SRE Series (high-voltage): 3V, 1-S0F



Lithium Capacitors (Li-C)

  • Radial Lead
    • HBR Series (high-temp): 3.8-2.SV, 10-220F
    • HBRL Series (low-temp): 3.8-2.SV, 10-220F
  • Pouch
    • HAA Series (low ESR): 2.5-4V, 1000-16,000F
    • HCC Series (EV): 2.2-3.8V, 1000-S000F



Modules

  • EDLC
    • SRM Series (double-cell module): 5.SV, 0.5-S0F
    • SSM Series (standard module): 80-160V, 5-21.7F
    • SMSP Series (standard module): 12-800V, 7.5-180F
  • LI-C
    • HMAA Series: 12-640V, 277-14,000F



*Contact us with requirements for custom solutions
